Fault judgment and solution of furniture cutting machine

In the process of using the whole house custom furniture cutting machine, we will always encounter some common small problems. How to solve the fault of the whole house custom cutting machine in time when the small problem turns into a big problem. Next, I will give you a detailed introduction to some knowledge of related aspects from the common faults, fault judgment methods and solutions, and hope to be of some help to you.

1. Processing overrun

Reason: This situation is usually caused by the value of the "physical coordinate position" + "substitute processing file size" of the machining zero point exceeding the large or small value set by "soft limit".

Judgment method: After the user defines the processing zero point, start processing and the X or Y axis exceeds the limit in a certain direction.

Solution: It can be solved by re-selecting the appropriate machining zero point.

2. The processing of the whole house custom furniture cutting machine is abnormally interrupted

Reason: The software limit area set by the user is smaller than the actual machining area of the machine tool.

Judgment method: The system can start the processing normally, and abnormal interruption occurs after a period of processing.

Solution: Change the software limit area to be larger than the actual processing area of the machine tool.

3.crash

Reason: voltage fluctuation

Judgment method: the screen prompts normal, but the value stops changing and pressing any key does not work; the screen prompts "Entering the power-off protection state, it may be that your power-off protection does not match the voltage. The screen prompts the current operation status display, press Any key does not work.

Solution: This situation generally occurs when the voltage fluctuates, which is similar to the power failure protection situation. Only when the voltage fluctuation is small, there is a screen prompt, and when the voltage fluctuation is too large, the screen cannot be displayed due to the reset circuit action of the power management chip in the control card. The above situation can basically be solved after adjusting the working voltage of the control card to 5.3V.

The above problems will inevitably occur during the processing of the whole house custom furniture cutting machine. In order to avoid better maintaining the working performance of the furniture cutting machine, we must maintain good usage and maintenance habits. In the process of using the engraving machine, there are still many points that need to be paid attention to. In the later period, Superstar CNC will introduce to you one after another, and I hope it will be helpful to you.
