Superstar CX-1625 Digital Oscillating Knife Cutting Machine

Product Overview

The Superstar CX-1625 (manufactured by Jinan Jinshengxing Machinery Manufacture Co., Ltd.) is designed to replace traditional manual clicking dies and hand cutting. It is a "Digital Die Cutter" that works directly from your CAD files (DXF, PLT, AI).

Whether you are cutting 50 layers of fabric for apparel or a single sheet of honeycomb cardboard for packaging, the oscillating knife technology ensures a perfectly vertical edge without the yellowing or hardening caused by laser heat. This makes it the only compliant choice for cutting PVC, rubber gaskets, and natural leather.

Core Advantages

• Zero Burnt Edges: Because it cuts with a physical blade oscillating at high frequency, there is no smoke, no smell, and no discoloration—critical for white fabrics and premium leather.

• Interchangeable Tool Heads: The modular head supports multiple tools: Oscillating Knife (for foam/board), Drag Knife (for vinyl), Creasing Wheel (for carton folding), and V-Cut Tool (for beveling).

• Intelligent Nesting: Integrated nesting software optimizes the layout of parts on expensive materials like leather, reducing waste by up to 20% compared to manual cutting.

• High-Speed Productivity: Driven by Panasonic/Delta Servo Motors, the machine reaches cutting speeds of up to 1200mm/s, making it 5-8 times faster than manual labor.

Detailed Configuration & Component Analysis

• Aviation Aluminum Table:

The bed is constructed from a honeycomb aluminum alloy structure. This ensures the table remains perfectly flat (essential for precise depth control) and does not deform under the immense suction of the vacuum pump.

• Japanese/Taiwanese Guide Rails:

We use high-precision linear guide rails (HIWIN or PMI) to ensure the cutting head moves smoothly at high accelerations. Stability here is key to preventing "jagged" cuts on curves.

• Safety Infrared Sensors:

The machine is equipped with an infrared safety barrier. If an operator's hand enters the working zone while the beam is moving, the machine stops instantly to prevent injury.

Applicable Industries & Materials

• Automotive Interiors: Cutting leather seat covers, floor mats, and steering wheel covers.

• Packaging: Prototyping and short-run production of corrugated boxes, honeycomb board, and grey board (creasing and cutting).

• Gaskets & Seals: Precision cutting of PTFE, rubber, silicone, and non-asbestos gasket sheets.

• Soft Signage: Cutting printed KT board, PVC foam board, and banners (using CCD camera registration).

Why Choose Superstar CNC?

• Eco-Friendly: No smoke or hazardous fumes means you don't need expensive air filtration systems, and your shop environment remains clean and safe.

• Versatility: One machine can handle 50+ different materials just by changing the blade tool, making it an incredibly flexible asset for job shops.

• Global Support: We provide remote TeamViewer support to help set up your cutting parameters for new materials, ensuring you get the best cut quality from day one.

Frequently Asked Questions (FAQ)

Q: Can this machine cut rigid plastic or wood?

A: It can cut semi-rigid plastics (like 3mm PVC or PP) using a milling router tool option. However, for wood or thick acrylic, we recommend our standard CNC Router series. This machine is specialized for flexible materials.

Q: How does the machine hold the material?

A: It uses a powerful vacuum table. The air is sucked through a porous felt mat, holding the fabric/leather firmly flat against the table.

Q: Does it have a camera for printed materials?

A: Yes, an optional CCD Visual System is available. It scans registration marks on printed banners or boards and automatically compensates for any distortion/stretching before cutting.

Q: What is the maintenance cost?

A: Very low. The main consumable is the blades (which are inexpensive) and the felt mat (which lasts a long time). There are no laser tubes or lenses to replace.

Precision Cutting Without the Burn

Upgrade to the clean, fast, and versatile Superstar CX-1625 Oscillating Knife Cutter.
