Product Overview
The Superstar CX-1325 (manufactured by Jinan Jinshengxing Machinery Manufacture Co., Ltd.) offers an incredibly cost-effective alternative to expensive fiber lasers for mid-to-thick metal plate cutting. Designed for harsh industrial environments, it features a heavy-duty gantry structure with a double-motor drive on the Y-axis, ensuring stable transmission and high accuracy even at rapid cutting speeds.
The machine is equipped with an intelligent Torch Height Control (THC) system (setting arc voltage/sampling arc voltage) and an integrated water cooling sink. This combination prevents the distortion of metal boards during processing, delivering smooth cuts that require little to no secondary grinding.
Core Advantages
Intelligent Arc Control: Features automatic arc starting with a success ratio of over 99%. The untouched plasma head ensures a small cutting edge and extends the lifespan of the consumables.
Water Sink Lathe Bed: The heavy steel bed includes a built-in water sink. This absorbs the immense heat generated during cutting, preventing the metal plate from warping and capturing plasma dust/fumes for a cleaner workshop.
High-Stability Gantry: A lightweight beam design paired with linear guide rails and a double motor driver on the Y-axis guarantees high-speed, vibration-free motion.
Flexible Power Options: Supports domestic plasma sources or premium imported options like USA Hypertherm or Thermadyne, depending on your thickness requirements and budget.
Technical Parameters
Feature | Specification |
Model Number | CX-1325 |
X, Y Working Area | 1300mm × 2500mm (Optional 1530 / 1640) |
Z-Axis Travel | 150mm |
Lathe Bed Structure | Seamless Steel Structure with Water Sink |
Machine Power | 8.5 KW |
Working Voltage | 380V / 50HZ (3-Phase) |
Reposition Precision | ±0.05 mm |
Processing Precision | ±0.1 mm |
Max. Cutting Speed | 1500 mm/min |
Cutting Thickness | 0 - 10mm (Standard 65A); Scalable with higher amps |
Torch Height Control | Auto / Manual (depending on configuration) |
Plasma Power Supply | Hypertherm 65A (USA) / Domestic Brands |
Control System | DSP / Shanghai Communication University System |
Motors | Stepper Motors (Servo optional) |
Software | FastCAM / Wentai (Compatible with Ucancam, Type3) |
Weight | 800 KG |
Detailed Configuration & Component Analysis
Included standard is FastCAM software, explicitly designed for plasma cutting. It optimizes the layout of your DXF/DWG parts on the metal sheet, maximizing material yield and generating efficient G-code automatically.
The 3-axis system utilizes square guide rails and high-precision gear-wheel (rack and pinion) transmission. This setup provides the rugged durability needed to push through heavy cutting loads in dusty metal shops.
The advanced numerical control system offers highly stable performance. It allows operators to easily adjust cutting speed and arc voltage directly from the console, adapting quickly to different metal types and thicknesses.
Applicable Industries & Materials
Advertising & Signage: Cutting intricate metal letters, logos, and outdoor signage.
HVAC & Ducting: High-speed cutting of galvanized steel for ventilation ducts and fittings.
Heavy Machinery & Auto: Manufacturing chassis brackets, boat building components, and agricultural machinery shells.
Compatible Materials: Carbon Steel, Stainless Steel, Galvanized Iron, Aluminum, Titanium, and Copper.
Why Choose Superstar CNC?
CE & ISO9001 Certified: All machines meet strict international quality and safety standards, ensuring reliable performance globally.
Customizable Configurations: Whether you need a larger 1500x3000mm bed, higher amperage power supplies (100A/120A/200A) for thicker cuts, or Servo motor upgrades, we can build the machine to your exact specs.
Global After-Sales Service: As the direct manufacturer, we provide complete technical support, including engineers available to service machinery overseas if required.
Frequently Asked Questions (FAQ)
Q: What is the maximum thickness this machine can cut?
A: With the standard 65A power supply, it cuts 0-10mm cleanly. If you need to cut thicker materials (up to 30mm or 50mm), we can equip the machine with a 100A, 160A, or 200A plasma source.
Q: Do I need an air compressor?
A: Yes, plasma cutting requires a steady supply of clean, dry compressed air to create the plasma arc and blow away the molten metal.
Q: What is the purpose of the water sink?
A: The water sink sits directly beneath the cutting slats. It serves two crucial purposes: it cools the metal sheet to prevent heat-warping (especially on thin sheets) and it traps the heavy smoke and sparks generated by the plasma arc.
Q: Can I use my own CAD software?
A: Yes. You can design your parts in any CAD software (AutoCAD, SolidWorks) and export them as DXF files. The included FastCAM software will import those files and generate the cutting path for the machine.
Cut Metal Faster and Cheaper
Reduce your fabrication costs without sacrificing edge quality. Contact Superstar CNC today for a customized quote on the CX-1325 Plasma Cutting Machine.
