Superstar CNC CX-B1 Multi-spindle Woodworking Cutting Machine for Funiture Cabinets

Superstar CX-B1 Pneumatic Multi-Spindle CNC Router for High-Volume Cabinet Production

Product Overview

The Superstar CX-B1 represents the perfect balance between cost-efficiency and industrial automation. Engineered by Jinan Jinshengxing Machinery, this "Four Process" CNC router addresses the critical pain point of downtime caused by manual tool changes. By mounting four separate spindles on the gantry, the machine can carry four different tools (e.g., 6mm cutter, 8mm cutter, V-bit, and profile cutter) and switch between them instantly via pneumatic cylinders. This configuration is widely regarded as the "Golden Standard" for small-to-medium cabinet makers who need speed but are not ready to invest in a Disc ATC machining center.

Core Advantages (The "Why Us")

• Instant Pneumatic Tool Switching: Eliminates the wait time associated with manual changes or linear ATC travel, increasing daily output by up to 30%.

• Heavy-Duty Industrial Structure: The bed is welded from thick-walled steel tubes and tempered to remove stress, ensuring the machine remains rigid and accurate even after years of high-speed operation.

• Cost-Effective Automation: Provides 80% of the functionality of a high-end ATC machining center at approximately 60% of the cost.

• Intelligent Dust Control: Independent dust hoods for each spindle ensure suction is concentrated only on the active tool, keeping the workshop cleaner.

• Vacuum Adsorption Table: Features a multi-zone vacuum table with a powerful pump to firmly hold down full sheets of MDF, plywood, or particleboard during aggressive cutting.

Technical Parameters

Detailed Configuration & Component Analysis

• Pneumatic Multi-Spindle System: We utilize high-quality pneumatic cylinders to raise and lower spindles. This design is less prone to mechanical failure than complex carousel ATC systems, offering high reliability for continuous production.

• Helical Rack & Pinion: Unlike straight racks, helical gears provide smoother engagement and higher torque transmission. This results in cleaner cut edges on melamine and laminated boards.

• Taiwanese Linear Guides: We strictly use genuine Hiwin or PMI rails. Their high load-bearing capacity ensures the gantry moves smoothly without jitter, which is critical for maintaining diagonal accuracy on cabinet doors.

Applicable Industries & Materials

• Panel Furniture: Kitchen cabinets, wardrobes, sliding doors, office desks.

• Woodworking: 3D relief carving, hollow cutouts, speaker boxes, musical instruments.

• Decoration: Acrylic cutting, PVC fabrication, MDF wall panels, soft metal (aluminum/copper) milling.

• Materials: MDF, Solid Wood, Plywood, Particle Board, PVC, Acrylic, Aluminum Composite Panel (ACP).

Why Choose Superstar CNC?

• Manufacturing Heritage: As Jinan Jinshengxing Machinery, we are not just a trading company; we are the factory. You get direct access to the engineers who built your machine.

• Quality Assurance: Every CX-B1 undergoes a 72-hour continuous run test before shipping to ensure zero defects.

• Global Support: We offer a 2-year warranty on core components and provide lifetime free remote technical support via WhatsApp/TeamViewer.

• Turnkey Solution: Includes ArtCAM/Type3 software training and a library of standard cabinet designs to get you started immediately.

FAQ

Q: What software is compatible with the CX-B1?

A: The machine accepts standard G-code. It is compatible with all major CAD/CAM software including ArtCAM, Type3, Ucancam, Aspire, and specialized cabinet software like Cabinet Vision or Polyboard (requires correct post-processor).

Q: Can this machine process a full 4x8 sheet of material?

A: Yes, the standard working area is 1300x2500mm, which perfectly fits standard 4x8 ft sheets. We also offer 1500x3000mm (5x10 ft) models for larger formats.

Q: How do I operate the 4 spindles? Do I need to stop the machine?

A: No. The switching is automatic. In your software, you assign Tool 1, Tool 2, etc., to different vectors. The machine controller reads the code and automatically activates the correct spindle instantly while running the file.

Q: What is the shipping method and packaging?

A: We wrap the machine in anti-rust plastic and secure it in a plywood crate or fix it directly onto a steel pallet for container loading. It is shipped via sea freight to your nearest port or door-to-door depending on your preference.

Ready to Streamline Your Cabinet Production?

Contact Superstar CNC today for a custom configuration and factory-direct pricing on the CX-B1.

Get Your Free Quote Now
