Superstar LFS13032-20000W Large Format Fiber Laser Cutting Machine

Product Overview

The Superstar LFS13032 (manufactured by Jinan Jinshengxing Machinery Manufacture Co., Ltd.) represents the pinnacle of heavy industrial laser cutting. When cutting thick steel plates (e.g., 30mm - 50mm+), traditional plasma or flame cutting methods leave severe thermal distortion and require extensive secondary milling. The 20,000W (20kW) fiber laser solves this, delivering clean, vertical edges on ultra-thick materials in a single pass.

The "Large Format" design (13 meters by 3.2 meters) allows entire oversized steel sheets to be loaded directly onto the bed via crane. Adopting professional display and nesting software, operators can design and arrange various graphics or texts for real-time, large-scale processing, minimizing scrap waste on highly expensive metal alloys.

Core Advantages

• Ultra-High 20kW Power: The 20,000W laser source provides immense energy density. It achieves rapid piercing and high-speed cutting on thick plates, replacing multiple lower-power machines and drastically reducing the cost-per-part.

• Massive Continuous Cutting Area: The 13m x 3.2m bed is specifically built for heavy industries. It allows for the uninterrupted cutting of oversized structural components without the downtime of indexing or shifting the metal plate.

• Modular Segmented Bed Design: To support the immense weight of thick steel plates, the machine bed is constructed using a heavy-duty, stress-relieved modular structure that distributes weight directly to the ground, ensuring absolute stability.

• Advanced Thermal Management: Cutting with 20kW generates extreme heat. The machine features high-temperature resistant shielding, a specialized heavy-duty cooling system, and zoned exhaust extraction to protect the machine frame and operator.

Technical Parameters

Detailed Configuration

• High-Power Auto-Focus Cutting Head:

Handling 20kW of optical power requires specialized optics. The cutting head is equipped with advanced internal cooling and protective glass monitoring. Its auto-focus mechanism instantaneously adjusts to pierce thick steel cleanly without "explosions."

• Heavy-Duty Transmission Dynamics:

Moving a massive gantry over a 13-meter span requires flawless synchronization. The combination of high-torque Servo motors and premium Taiwan YYC gear racks ensures rapid acceleration (1-3G) and eliminates backlash, even over ultra-long travel distances.

• Intelligent Software & Nesting:

The professional software suite allows for real-time monitoring and advanced nesting of complex geometries. It calculates the most efficient cutting paths across the massive 13m bed, significantly optimizing gas usage and cycle times.

Applicable Industries & Materials

Designed for extreme durability, this machine is widely suitable for the fast cutting of standard and exotic metals:

• Target Industries: Shipbuilding, construction machinery, agricultural equipment, locomotive manufacturing, pressure vessels, steel structure engineering, and aerospace components.

• Compatible Materials: Stainless steel, carbon steel, alloy steel, silicon steel, galvanized steel plate, nickel-titanium alloy, chromium-nickel-iron alloy, aluminum plates, and brass.

Why Choose Superstar CNC?

• Heavy Industry Expertise: Manufacturing a 13-meter, 20kW laser requires advanced engineering. Jinan Jinshengxing Machinery has the large-scale manufacturing facilities necessary to mill and anneal these oversized machine beds precisely.

• Comprehensive Safety Protocols: Operating at 20kW requires stringent safety measures. Our machines integrate multi-zone dust extraction, heavy-duty light curtains, and robust radiation shielding.

• Turnkey Installation & Training: Due to the scale of this equipment, we provide expert on-site or guided installation, alongside thorough software and maintenance training for your engineering team.

Frequently Asked Questions

Q: Can this machine handle continuous 24/7 operation at full power?

A: Yes. The LFS13032 is strictly an industrial-grade machine. The heavy-duty frame, premium servos, and high-capacity dual-temperature chiller are engineered specifically to run continuously in demanding, multi-shift heavy fabrication environments.

Q: How do you ship a machine that is 13 meters long?

A: The machine bed utilizes a modular, segmented design. It is securely packed into standard shipping containers and precision-assembled and calibrated at your facility by our technicians or under our direct guidance.

Q: What is the maximum cutting thickness for carbon steel at 20,000W?

A: A 20kW fiber laser is capable of cutting carbon steel plates up to 50mm - 60mm (and sometimes thicker, depending on edge quality requirements and oxygen assist gas parameters). It provides a bright, smooth finish on thick plates that lower-power lasers cannot achieve.

Dominate Heavy Metal Fabrication

Take on the largest, thickest jobs with confidence. Scale up your shipyard or steel plant with the Superstar LFS13032-20000W Large Format Fiber Laser.

Request a Consultation & Factory Quote
