Product Overview
The Superstar CX-368D (manufactured by Jinan Jinshengxing Machinery Manufacture Co., Ltd.) represents a major upgrade in woodworking finishing technology. In standard edge banding, the sharp corners of cabinet doors often require manual filing or secondary processing. The CX-368D eliminates this bottleneck by integrating a specialized corner rounding station directly into the continuous automated workflow.
Featuring a heavy-duty frame and an intelligent automatic tracking structure, the machine ensures that the upper and lower parts of the trimmed sheet remain perfectly flat and smooth, even during high-speed feeding. It is the ideal investment for wardrobe, desk, and custom kitchen cabinet manufacturers demanding precision and efficiency.
Core Advantages
Automatic Corner Rounding: The integrated corner profiling unit automatically tracks the front and rear corners of the panel, milling them into a smooth, seamless radius. This is essential for high-quality, safe, and aesthetically pleasing cabinet fronts.
High-Frequency Trimming Motors: The rough and fine trimming stations utilize high-speed, high-frequency motors (typically 12,000 to 18,000 RPM) to ensure a perfectly clean cut without chipping the edge tape or the board's melamine surface.
Precision End-Cutting: Features an intelligent tracking mechanism. As the board moves along the conveyor, the dual saws travel with it momentarily to execute a perfect 90-degree flush cut at both the leading and trailing ends.
Robust & Stable Operation: Built on a heavily welded and tempered steel frame, the machine absorbs vibration from the high-speed motors, guaranteeing that all milling and scraping knives remain perfectly aligned with the board over years of continuous shifts.
Technical Parameters
Feature | Specification |
Model | CX-368D Full Automatic Edge Banding Machine |
Primary Functions | Gluing, End Cutting, Rough Trimming, Fine Trimming, Corner Rounding, Scraping, Buffing |
Feeding Speed | [e.g., 15 - 20 m/min (Adjustable)] |
Panel Thickness | 10 mm - 60 mm |
Edge Tape Thickness | 0.4 mm - 3.0 mm |
Min. Panel Length | ≥ 120 mm |
Min. Panel Width | ≥ 60 mm |
Edge Tape Material | PVC, ABS, Acrylic, Melamine, Wood Veneer |
Panel Material | MDF, Particleboard, Plywood, Solid Wood |
Air Pressure Required | 0.6 MPa (6 Bar) |
Total Motor Power | [e.g., 10.5 KW - 12.5 KW] |
Working Voltage | AC 380V / 50HZ / 3-Phase |
Detailed Configuration
The Teflon-coated glue pot prevents hot melt adhesive from burning. The multi-roller pressing unit (one large motorized roller and supplementary pressure rollers) squeezes out air bubbles and ensures a tight, invisible bond line.
Following the trimming and corner rounding units, the scraping station uses a super-hard alloy R-knife to scrape away any fine machining lines left by the rotary cutters, making the edge perfectly round and smooth to the touch.
The final station features independent cloth polishing wheels. They rapidly polish the top and bottom edges of the panel, removing any squeezed-out glue and restoring the factory color and sheen to the PVC tape.
Applicable Industries & Materials
Custom Cabinetry: Manufacturing high-end kitchen cabinets, bathroom vanities, and wardrobe doors with seamless, rounded corners.
Office Furniture: Desks, conference tables, and bookshelves requiring durable, thick PVC edge protection.
Commercial Displays: Retail shelving and exhibition booths made from melamine-faced chipboard (MFC) or MDF.
Interior Doors: Straight-line edge sealing for composite and flush wooden doors.
Why Choose Superstar CNC?
Complete Furniture Production Lines: Jinan Jinshengxing Machinery manufactures a full ecosystem of equipment. Pair the CX-368D with our CNC Nesting Routers and Side Drilling Machines for a fully synchronized smart factory.
User-Friendly Control: Operated via a high-definition PLC touch screen. It provides clear visual feedback and fault alarms, allowing operators to turn individual functional stations on or off effortlessly.
Global Export Quality: All edge banders meet strict EU CE certification standards, featuring enclosed safety hoods, anti-pinch devices, and premium pneumatic components for reliable global operation.
Frequently Asked Questions
Q: What is the difference between this machine and standard edge banders?
A: Standard edge banders only flush-cut the ends and trim the top/bottom edges, leaving sharp 90-degree corners. The CX-368D includes a specific Corner Rounding station that profiles these sharp corners into a smooth, curved radius, which is highly sought after in premium cabinet making.
Q: Does it have a Pre-Milling function?
A: The CX-368D focuses on Corner Rounding. If your panels suffer from saw-blade chipping or uneven cuts and you require a "Pre-Milling" station before gluing, please inquire about our expanded models (such as the CX-465D).
Q: How long does the glue pot take to heat up?
A: Typically, it takes 20 to 30 minutes to reach optimal operating temperature, depending on the ambient factory temperature and the specific hot melt glue used.
Deliver Premium Finishes Automatically
Eliminate manual corner sanding and deliver flawless cabinet doors. Upgrade your production line with the Superstar CX-368D Corner Rounding Edge Banding Machine.
